How to Root Huawei P10 Lite WAS-LX1A and Install TWRP Recovery

If you are a owner of a Huawei P10 Lite smartphone, and also want to customize this rugged smartphone, then you have visited the right page.

The Huawei P10 Lite is certainly for those users, who prefer stylish and powerful devices, the smartphone doesn’t compromise with both of them. It features 2.5d double-sided curved glass, with diamond-cut metal frame, stylish and clean design, which intends to please at first sight. The P10 is sold in the various color variants including midnight black, platinum gold and pearl white. With the 2.5d double-sided glass, the phone’s looks becomes gorgeous, and it’s 7H hardness makes it scratch resistant and protects it from damages against bumps. The ‘Water’ is what inspires the ‘P10’ lite most, as it’s blue variant reflects the rippling waves which changes according to the lighting conditions. The phone’s aluminum and magnesium body is built using CNC process, with bright body due to ceramic blasting, and textured finish and rounded edges makes the smartphone a perfect choice. The 5.2-inch RGB color scheme equipped display supports full-HD resolution, and displays 21% more color, and the body is up to 20% thinner. The phone supports fast charging for it’s 300 mAh (TYP) battery, a 10 minutes charge can run the phone for 2 hours. The device runs on Huawei Kirin 658 processor, coupled with Fingerprint sensor, EMUI 5.1 UX, and is available in 3GB and 4GB RAM variants.

If you are an Android Enthusiast, and want to Root and Install TWRP recovery on your beloved, then you have landed on the right page. In the due course of the article, we will guiding you through the process to install TWRP and root Huawei P10 Lite.

The TWRP features the material design, and attractive user interface (UI), and by following this guide you can install latest TWRP for Huawei P10 Lite. You can download TWRP Recovery from the links provided in the pre-requisite section of this article. Kindly note that this is a official TWRP recovery and is only for Huawei P10 Lite (Kindly confirm the model by going to Settings>About). The process given below is merely for rooting and installing TWRP on Huawei P10 Lite, do not try out this method on any other device.

If you want to unleash the full potential of the hardware of your Huawei P10 Lite, then rooting and flashing the TWRP is the main concern. The Stock ROMs have often limited and unsupported features in the sense of Customization. When you have a rooted device and also flashed TWRP recovery, then you are free to install any Custom ROMs, Mods, Kernel, and Xposed etc., as well as many apps which requires root access to work properly.

Brief Details and Advantage of TWRP Recovery

TWRP (Team Win Recovery Project) is an open source, community development project. By flashing the TWRP, your device will be enabled to install any custom firmware, rooting your smartphone, mod zip files for customizations, Xposed Modules for customized features, one click root and unroot processes. Apart from that, it allows you to take Full Nandroid Backup and restore it later, one click image file flashing, remove bloatware, overclock and underclock. Using TWRP, one can easily clean Wipe, Cache and Data after flashing any image file to reflect the changes and rectify minor errors due to cache.

For installing the TWRP, your Huawei P10 Lite phone must have the Unlocked bootloader. That means you have to firstly unlock the bootloader to root your device as well doing any customization.

Disclaimer: The AndroidWeblog.com covers although everything in a very neat and a processed manner so that our readers get exactly what they want, still there are meager chances of basic issues that may arise out of the listed steps here. Hence it is in sole interest of the user to follow the steps very cautiously so as to stay away from any mishappenings with your device.

Rooting and flashing the Custom ROM firmware, certainly without any doubt voids your devices warranty and AndroidWeblog.com in no way will be held responsible for warranty void or your bricked device.

Prerequiste

Ensure to check your model number, which must be:

  • Huawei P10 Lite

You must have to ensure that prior to rooting your phone , you have read thoroughly the disclaimer and you agree to proceed further on your risk.

  • Phone Should be Charged

Your phone must be 70% charged atleast else, it may lead to complications sometimes while experimenting. Why to take risk, try to charge it fully.

  • Back Up

If you are either going to root your phone or install a Custom ROM, it is a good habit to make a back up of your phone. Make a back up of all your media like images, videos and all on your PC and your contacts on Cloud.

  • Enable USB Debugging

You must enable USB debugging option by going in to Settings, Applications and Developer options.

Downloads For Rooting Huawei P10 Lite

Download Universal ADB Drivers here (If your PC have already drivers installed then skip this)

Download platform-tools/ SDK Tools package from Android SDK on PC from here. (Android command line tools> SDK Tools package)

Download TWRP Recovery for Huawei P10 Lite from here:

TWRP Recovery (Login required)

TWRP Recovery 3.3.1

Download SuperSU by Chainfire from here.

Steps to Flash/ Install TWRP on Huawei P10 Lite

Step 1: Assuming you have already downloaded the platform-tools from Android SDK (SDK Manager) platform-tools on your PC. The platform-tools contains the required adb and fastboot binaries.

Step 2: Make sure that the drivers are installed on your computer. Then, skip to the next step.

Note: If Developer Settings and USB Debugging settings are already enabled on your device, as suggested in Prerequisite section, then simply skip the Step 3 and Step 4, and follow Step 5 directly.

Step 3: Now, enable the developer settings on your Huawei P10 Lite Device. To achieve the same, just navigate to the Settings -> About and then find the ‘Build Number ‘, and then tap on ‘Build Number’ for 7 times, this will enable the developer settings on your device.

Step 4: If you have USB Debugging already, then skip this step. If you have not, then open the Developer Options and then enable USB debugging option.

Step 5: Now, open the command prompt in computer/ ADB Terminal, and simply type the command:

adb reboot bootloader

Step 6: Your device should have not entered into fastboot mode. Now copy the TWRP.img file downloaded in prerequisite section, to the same folder where adb and fastboot binaries are located. Rename the file to ‘twrp.img’ and then enter this command:

fastboot flash recovery twrp.img

and then run this command, type:

fastboot reboot

Step 7 (Important): Some devices might not replace the custom recovery automatically during the first boot. You can search Google for key combinations to enter your device into recovery mode. After running the ‘fastboot reboot’ command, press and hold the proper key combination to enter device into TWRP Mode. Once the device boots to TWRP mode, the TWRP will automatically patch the stock ROM, to prevent the chances of replacing TWRP with Stock Recovery.

After typing fastboot reboot, hold the key combo and boot to TWRP. Once TWRP is booted, TWRP will patch the stock ROM to prevent the stock ROM from replacing TWRP. If you don’t follow this step, you will have to repeat the install.

Procedure to Root Huawei P10 Lite/ Install SuperSU

Make sure that you have downloaded SuperSU (link in pre-requisite section of this article). Then, proceed to the steps.

Step 1: Transfer the downloaded SuperSU.zip file to the internal storage / SD card of your Huawei P10 Lite smartphone.

Step 2: Now, just boot into the recovery. From the TWRP interface, you can optionally backup the Stock ROM. Though, I would recommend to backup the Stock ROM. Because if in case process gets failed, you can flash the Stock ROM.

Install TWRP 3;0

Step 3: Tap on Install ‘, and then navigate to the file ‘SuperSU.zip’ and swipe to confirm flash (located at the bottom of the screen). The flashing process of SuperSU has been started and will take few seconds to complete.

Congratulations, now you have rooted Huawei P10 Lite and also flashed the TWRP. Now, you can install Xposed Framework, and customize your smartphone as per your preference. If you wish to verify, you may download and check the Root Status through Root Checker app.

Ramandeep Singh

Meet Ramandeep Singh, the face behind AndroidWeblog.com. The Founder and the Ex-Editor-in-Chief (2011-2013) of the renowned website 'TechClap.com' which was dedicated to providing the most reliable and comprehensive information and analysis related to technology. A passionate and dynamic blogger, he aims to deliver quality content to IT professionals and those who share his passion for Android, technology and gadgets.

Related Articles

One Comment

  1. fastboot flash recovery C:UsersTessryDesktopP10_LiteRecovery.img
    target reported max download size of 471859200 bytes
    sending ‘recovery’ (24498 KB)…
    OKAY [ 0.653s]
    writing ‘recovery’…
    FAILED (remote: Command not allowed)
    finished. total time: 0.664s

    HELP???
