How to Root Honor 9 EMUI 5.1 and Install TWRP Recovery

If you are an owner of a Huawei Honor 9 smartphone running on EMUI 5.1, and also want to customize this rugged smartphone, then you have visited the right page.

The flagship device from Huawei, the Honor 9 is stunning from the every angle, as far as the design is concerned. It boasts of a 3D Curved Glass, and is perfect example of a unsparing craftsmanship. The Dual-lens technology is upgraded by the company over Honor 9’s predecessor models. It offers the superior low-light shooting, with the dual-lens hybrid zoom. The device is equipped with the Huawei Histen 3D audio technology, which is ultra-wide 3D sound field technology and makes users enjoy the virtual surround sound through the earphones in three modes, which are near, front and wide, and it according replicate the effect. Further, the audio fine-tuning by Rainer Mailler ensures that phone outputs the high level of sound quality, regardless of music genre. The Kirin 960 chipset powers the device, while the EMUI 5.1 runs on tops of the device’s Android 7 Nougat operating system. The Kirin 960 is reportedly 18% stronger than its predecessor, and ensures the long battery life. With the 6GB of RAM and 64GB of internal storage, the device is all packed with to deliver smoother performance. The display measures 5.15-inch, which features 428 PPI, and delivers the true-to-life color reproduction. The device’s display looks great on all lighting conditions, including sunlight, night etc. A 3200 mAh battery powers the device, and the Smart Power 2.0 makes the phone to play music for up to 78 hours, while supporting the 9V/2A SuperCharge technology, which is claimed to charge the phone from 0 to 40% in just half an hour. The device features the front-facing fingerprint sensor, which quickly unlocks the device.

If you are an Android Enthusiast, and want to Root and Install TWRP recovery on your beloved, then you have landed on the right page. In the due course of the article, we will guiding you through the process to install TWRP and root Honor 9.

The TWRP features the material design, and attractive user interface (UI), and by following this guide you can install latest TWRP for Honor 9. You can download TWRP Recovery from the links provided in the pre-requisite section of this article. Kindly note that this is a official TWRP recovery and is only for Honor 9 (Kindly confirm the model by going to Settings>About). The process given below is merely for rooting and installing TWRP on Honor 9, do not try out this method on any other device.

If you want to unleash the full potential of the hardware of your Honor 9, then rooting and flashing the TWRP is the main concern. The Stock ROMs have often limited and unsupported features in the sense of Customization. When you have a rooted device and also flashed TWRP recovery, then you are free to install any Custom ROMs, Mods, Kernel, and Xposed etc., as well as many apps which requires root access to work properly.

Brief Details and Advantage of TWRP Recovery

TWRP (Team Win Recovery Project) is an open source, community development project. By flashing the TWRP, your device will be enabled to install any custom firmware, rooting your smartphone, mod zip files for customizations, Xposed Modules for customized features, one click root and unroot processes. Apart from that, it allows you to take Full Nandroid Backup and restore it later, one click image file flashing, remove bloatware, overclock and underclock. Using TWRP, one can easily clean Wipe, Cache and Data after flashing any image file to reflect the changes and rectify minor errors due to cache.

For installing the TWRP, your Honor 9 phone must have the Unlocked bootloader. That means you have to firstly unlock the bootloader to root your device as well doing any customization.

Disclaimer: The AndroidWeblog.com covers although everything in a very neat and a processed manner so that our readers get exactly what they want, still there are meager chances of basic issues that may arise out of the listed steps here. Hence it is in sole interest of the user to follow the steps very cautiously so as to stay away from any mishappenings with your device.

Rooting and flashing the Custom ROM firmware, certainly without any doubt voids your devices warranty and AndroidWeblog.com in no way will be held responsible for warranty void or your bricked device.

Prerequiste

Ensure to check your model number, which must be:

  • Honor 9 (EMUI 5.1) STF-L09, STF-AL00, STF-TL10, STF-AL10, STF-L*

You must have to ensure that prior to rooting your phone , you have read thoroughly the disclaimer and you agree to proceed further on your risk.

  • Phone Should be Charged

Your phone must be 70% charged atleast else, it may lead to complications sometimes while experimenting. Why to take risk, try to charge it fully.

  • Back Up

If you are either going to root your phone or install a Custom ROM, it is a good habit to make a back up of your phone. Make a back up of all your media like images, videos and all on your PC and your contacts on Cloud.

  • Enable USB Debugging

You must enable USB debugging option by going in to Settings, Applications and Developer options.

  • Unlocked Bootloader

The bootloader of the device must have already unlocked.You must unlock before proceeding with the steps below.

Downloads For Rooting Honor 9

Download Universal ADB Drivers here (If your PC have already drivers installed then skip this)

Download platform-tools/ SDK Tools package from Android SDK on PC from here. (Android command line tools> SDK Tools package)

Download TWRP Recovery for Honor 9 from here:

TWRP Recovery 3.1.1.0. (Login required)

Download SuperSU by Chainfire from here.

Steps to Flash/ Install TWRP on Honor 9

Step 1: Assuming you have already downloaded the platform-tools from Android SDK (SDK Manager) platform-tools on your PC. The platform-tools contains the required adb and fastboot binaries.

Step 2: Make sure that the drivers are installed on your computer. Then, skip to the next step.

Note: If Developer Settings and USB Debugging settings are already enabled on your device, as suggested in Prerequisite section, then simply skip the Step 3 and Step 4, and follow Step 5 directly.

Step 3: Now, enable the developer settings on your Honor 9 Device. To achieve the same, just navigate to the Settings -> About and then find the ‘Build Number ‘, and then tap on ‘Build Number’ for 7 times, this will enable the developer settings on your device.

Step 4: If you have USB Debugging already, then skip this step. If you have not, then open the Developer Options and then enable USB debugging option.

Step 5: Now, open the command prompt in computer/ ADB Terminal, and simply type the command:

adb reboot bootloader

Step 6: Your device should have not entered into fastboot mode. Now copy the TWRP.img file downloaded in prerequisite section, to the same folder where adb and fastboot binaries are located. Rename the file to ‘twrp.img’ and then enter this command:

fastboot flash recovery twrp.img

and then run this command, type:

fastboot reboot

Step 7 (Important): Some devices might not replace the custom recovery automatically during the first boot. You can search Google for key combinations to enter your device into recovery mode. After running the ‘fastboot reboot’ command, press and hold the proper key combination to enter device into TWRP Mode. Once the device boots to TWRP mode, the TWRP will automatically patch the stock ROM, to prevent the chances of replacing TWRP with Stock Recovery.

After typing fastboot reboot, hold the key combo and boot to TWRP. Once TWRP is booted, TWRP will patch the stock ROM to prevent the stock ROM from replacing TWRP. If you don’t follow this step, you will have to repeat the install.

Procedure to Root Honor 9/ Install SuperSU

Make sure that you have downloaded SuperSU (link in pre-requisite section of this article). Then, proceed to the steps.

Step 1: Transfer the downloaded SuperSU.zip file to the internal storage / SD card of your Honor 9 smartphone.

Step 2: Now, just boot into the recovery. From the TWRP interface, you can optionally backup the Stock ROM. Though, I would recommend to backup the Stock ROM. Because if in case process gets failed, you can flash the Stock ROM.

Install TWRP 3;0

Step 3: Tap on Install ‘, and then navigate to the file ‘SuperSU.zip’ and swipe to confirm flash (located at the bottom of the screen). The flashing process of SuperSU has been started and will take few seconds to complete.

Congratulations, now you have rooted Honor 9 and also flashed the TWRP. Now, you can install Xposed Framework, and customize your smartphone as per your preference. If you wish to verify, you may download and check the Root Status through Root Checker app.

Credits:  OldDroid

Source: XDA
